Dimensions
Item | K | DIM2 | DIM3 | DIM4 | DIM5 | DIM6 |
HZ28-1 | 16 | 26 | 55 | 80 | 40 | 92 |
HZ28-2 | 10 | 20 | 55 | 80 | 40 | 92 |
HZ28-3 | 16 | 26 | 67.5 | 48 | 24 | 82 |
HZ28-4 | 10 | 20 | 67.5 | 48 | 24 | 82 |
Technical parameter
Item | Style | Rated Speed | Rail Width | rail surface positive pressure Fy | rail surface side pressure Fx | Car Rated Load (Sug.) | |
CAR | CWT | K(mm) | |||||
HZ28 | Sliding | 2.0m/s | N/A | 10,16 | 700N | 1200N | 1350KG |
